EBOX V3 has finally arrived! You wanted more power, more punch, more range, more control and a higher top speed?? We listened to you, and we delivered all of that and more, featuring the brand new EBX powertrain! Bigger batteries, a Fardriver 80A controller and a high power PMSM motor with encoder and temperature feedback with up to 6.3kW. There are no hall sensors to fail and the precise control of the encoder, provides laser sharp coil firing for increased efficiency and maximum performance. Added to that we have included a colour TFT display with 3-speed modes and fault-finding capability. Our warranty has been increased to 1 year, (or 1000 miles) on all powertrain components (battery, controller, motor).
What does this mean? Basically, peaking top speeds of up to 55 mph! New colourways, new tyres and all in the same mini package you can throw in the trunk of your car.
.
SPECS
Frame type
V3 Double Cradle
Front wheel size
14"
Rear wheel size
12"
Fork
150mm travel USD
Rear Suspension
Progressive mono shock 150mm travel
Bar Risers
Alloy Cast 36mm rise Ø22.2
Front brake
Hyraulic Disc (Right lever) e-moto brakes
Front disc
180mm rotor, 4 bolt
Rear brake
Hyraulic Disc (Left lever) e-moto brakes
Rear disc
180mm rotor, 4 bolt
Front tyre
Upgraded 60/100-14 Dirt
Rear tyre
Upgraded 80/100-12 Dirt
Chain
219H 120L
Gearing
Front 10T, Rear 70T
Max load
85kg
Handlebar
EBOX Race 6061 T6 29.5" x 7", with 3 piece crossbar and bar pad
Seat
EBOX fat seat
Motor
EBX PMSM motor with temp feedback and encoder
Rated Power
5.4KW
Peak power
6.3KW (8.5hp)
Max RPM
9,000
Battery
72v 25 Ah battery with smart BMS 21700 Cells potted in steel case with Qs8 connector and air breaker switch
Controller
80 Amp Fardriver controller
Throttle
SURRON style full twist
Display
TFT odometer display with 3 speed modes and fault code analysis software
Connectors
Automotive connectors with sealed wiring harness
Headlight
LED headlight and switch
Charger
AC 100-240V, Output: 84V, 6A
TECH
Charge time
4-5 hours
Range
28-31 miles (45-50Km)
Top speed
55mph (89Km/h)
External adjustability
3 riding modes
Frame construction
V3 wide frame (190mm) large capacity battery, race inspired revised geometry,
Increased fork travel, increased pre-load and heavier oil, dropper footpeg bar.
Waterproof
IP54
Other
USB A + C charging port
Wheelbase
980mm
Seat height
650mm
Warranty
EBX 1 year/1000 miles (whichever comes first) powertrain warranty. 6 month parts warranty. See T&C's for more information
